RLC Meter Calibrator
Impedance Calibrator
Model: M550
Manufacturer: Meatest
- Impedance calibrator has been developed esspecially for calibration of RCL meter
- Resistance range: 0.1 Ω to 100 MΩ
- Capacitance range: 10 pF - 100 μF
- Inductance range: 10 μH - 10 H
- Frequency: 20Hz to 1 MHz
- Interface: GPIG and RS-232
- Accuracy up to 0.005% (Resistance standard)
High resistance decade
Model: M191
Manufacturer: Meatest
- Total resistance range 10.00 kΩ to 1000.0 GΩ
- Resistance accuracy 0.1 to 5 %
- Test voltage range 10 000 VDC + 5%
- Test voltage accuracy indication 0.5 % + 10 V
- Test current indication 4 digit from 0.01 pA to 99.99 mADC
- Programmable high resistance decade box
- Short current verification
- Dielectric and absorption parameters simulation
- High voltage capacitance in three fix points 10, 50, 100 nF
- HIPOT timer verification
